Description and Technical Data:
1) Overview/Key Features
The ALINX AXKU040 V2.0 is a Kintex™ UltraScale™ FPGA development board and design-in kit based on the AMD/Xilinx XCKU040-2FFVA1156I device. The board combines an FPGA system-on-module with a carrier board and provides high-speed memory, PCIe, SFP+, FMC HPC, FMC LPC and Gigabit Ethernet interfaces. It is suitable for data-center acceleration, network and storage acceleration, industrial, scientific and medical equipment, machine vision, wired communications, optical transport, radio and wireless-baseband applications.
Key features include:
- AMD/Xilinx Kintex UltraScale XCKU040 FPGA
- 4 GB DDR4 SDRAM
- 2 × 32 MB QSPI Flash
- 20 GTH high-speed transceivers
- PCIe interface
- SFP+ interface
- FMC HPC interface
- FMC LPC interface
- Gigabit Ethernet
- HDMI-oriented video application support
- Compatible with multiple FMC expansion cards
- System-on-module and carrier-board design
- FAN8060 heatsink kit, preinstalled
NCNR non cancelable - non returnable product. B2B customers please contact Mirifica Industrial for volume quotes. Mirifica Industrial ships world-wide.
2) Tech Specs
| Specification | Detail |
|---|---|
| Product model | AXKU040 V2.0 |
| Product type | FPGA development board and design-in kit |
| FPGA family | AMD/Xilinx Kintex UltraScale |
| FPGA device | XCKU040-2FFVA1156I |
| FPGA package | FFVA1156 |
| DDR4 SDRAM | 4 GB |
| QSPI Flash | 2 × 32 MB |
| High-speed transceivers | 20 × GTH |
| PCIe | Available |
| SFP+ | Available |
| FMC HPC | Available |
| FMC LPC | Available |
| Ethernet | Gigabit Ethernet |
| Video support | HDMI application support |
| Board architecture | FPGA system-on-module with carrier/base board |
| Cooling | FAN8060 heatsink kit, preinstalled |
| Board revision | V2.0 |
3) Tech Support/Dokuments
Web available technical information usually covers the AXKU040 V2.0 board architecture, XCKU040 FPGA, DDR4 SDRAM, QSPI Flash, GTH transceivers, PCIe, SFP+, FMC HPC, FMC LPC, Gigabit Ethernet, compatible FMC cards, supported applications, product-selection information, documentation, demonstrations, tutorials and package contents. The board is a design-in kit intended to help accelerate development of Kintex UltraScale-based applications.
Contact Mirifica Industrial for further detailed information for your project.
