Description and Technical Data:
1) Overview/Key Features
The AXU5EVB-P is a high-performance Zynq UltraScale+ MPSoC development board and evaluation kit based on the XCZU5EV-2SFVC784I adaptive SoC. The kit combines a pluggable ACU5EV system-on-module with a feature-rich base board, providing DDR4 memory, eMMC and QSPI Flash, PCIe, FMC expansion, SFP+, M.2 storage, video interfaces, USB 3.0, CAN, RS485, and high-speed communication interfaces.
- Quad-core ARM Cortex-A53 processor operating at up to 1.3 GHz.
- Dual-core ARM Cortex-R5F processor operating at up to 533 MHz.
- Mali-400 MP2 GPU.
- H.264 and H.265 video codec support.
- 16 nm FinFET+ programmable logic fabric.
- 4 x Panasonic board-to-board connectors.
- 4 GB 64-bit DDR4 SDRAM for the processing system.
- 1 GB 16-bit DDR4 SDRAM for the programmable logic.
- 32 MB QSPI Flash.
- 32 GB eMMC Flash.
- 1 x FMC LPC connector.
- 2 x SFP+ interfaces supporting up to 12.5 Gbps per line.
- 2 x Gigabit Ethernet interfaces: 1 x processing-system interface and 1 x programmable-logic interface.
- 1 x PCIe Gen3 x2 interface.
- 1 x M.2 card slot connected to the processing system.
- 2 x USB-to-UART interfaces: 1 x processing-system interface and 1 x programmable-logic interface.
- 1 x DisplayPort interface connected to the processing system.
- 1 x 2-lane MIPI interface connected to the programmable logic.
- 2 x CAN interfaces.
- 2 x RS485 interfaces.
- 4 x USB 3.0 interfaces.
- 2 x HDMI interfaces: 1 x HDMI input and 1 x HDMI output.
- 1 x MicroSD card interface.
- 1 x real-time clock.
- 4-Kbit I2C serial EEPROM and 1 x LM75 temperature sensor.
- Compatible with FMC cards for data acquisition, motor control, display, camera interfaces, and software-defined radio.
- Suitable for artificial intelligence, deep learning, automotive, machine vision, video and image processing, medical equipment, industrial control, data centers, cloud computing security, and wired or wireless communications.
NCNR non cancelable - non returnable product. B2B customers please contact Mirifica Industrial for volume quotes. Mirifica Industrial ships world-wide.
2) Tech Specs
| Specification | Detail |
|---|---|
| MPSoC device | XCZU5EV-2SFVC784I |
| MPSoC family | Zynq UltraScale+ MPSoC |
| MPSoC package | SFVC784 |
| MPSoC speed grade | -2 |
| Processor cores | Quad-core Cortex-A53 and dual-core Cortex-R5F |
| Cortex-A53 frequency | Up to 1.3 GHz |
| Cortex-R5F frequency | Up to 533 MHz |
| GPU | Mali-400 MP2 |
| Video codec | H.264 and H.265 |
| Process technology | 16 nm FinFET+ |
| Board-to-board connectors | 4 x Panasonic connectors |
| DDR4 SDRAM for processing system | 4 GB, 64-bit |
| DDR4 SDRAM for programmable logic | 1 GB, 16-bit |
| QSPI Flash | 32 MB |
| eMMC Flash | 32 GB |
| FMC interface | 1 x FMC LPC |
| FMC LPC I/O | 36 LVDS pairs at 1.8 V |
| SFP+ | 2 x SFP+, up to 12.5 Gbps per line |
| Gigabit Ethernet | 2 x interfaces: 1 x processing-system and 1 x programmable-logic |
| PCI Express | 1 x PCIe Gen3 x2 |
| M.2 | 1 x M.2 card slot connected to the processing system |
| UART | 2 x USB-to-UART interfaces |
| DisplayPort | 1 x processing-system interface |
| MIPI | 1 x 2-lane programmable-logic interface |
| CAN | 2 x CAN interfaces connected to the processing system |
| RS485 | 2 x RS485 interfaces connected to the programmable logic |
| USB | 4 x USB 3.0 interfaces |
| HDMI | 2 x interfaces: 1 x input and 1 x output |
| Removable storage | 1 x MicroSD card interface |
| EEPROM | 1 x 4-Kbit I2C serial EEPROM |
| Temperature monitoring | 1 x LM75 temperature sensor |
| Real-time clock | 1 x RTC |
| LED indicators | 1 x power LED, 1 x done LED, and 1 x programmable-logic LED |
| Push buttons | 1 x reset key, 1 x processing-system key, and 1 x programmable-logic key |
| Power input | 12 V single supply |
| Board dimensions | 200 x 111 mm |
3) Tech Support/Dokuments
Web available technical information usually covers the AXU5EVB-P product overview, MPSoC architecture, system-on-module and base-board features, applications, technical specifications, product selection information, documentation, related products, and package contents.
There are the following technical resources:
- AXU5EVB-P V3.0 User Manual dated 2026-08-04.
- AXU5EVB-P V2.0 User Manual dated 2025-07-15.
- Technical information concerning DDR4 SDRAM, eMMC Flash, QSPI Flash, PCIe, FMC LPC, SFP+, M.2, Gigabit Ethernet, DisplayPort, HDMI, MIPI, USB 3.0, CAN, RS485, UART, MicroSD, EEPROM, real-time clock, temperature monitoring, LEDs, keys, power, and board dimensions.
- Development demos and tutorials.
- Design-in information for Zynq UltraScale+ MPSoC-based artificial intelligence, video, industrial, automotive, medical, and communications applications.
Contact Mirifica Industrial for further detailed information for your project.
4) Related Product Suggestion
Available related products and add-on products mentioned for the AXU5EVB-P include:
- AXU4EVB-P Dev Board & Kit with Zynq UltraScale+ MPSoC ZU4EV.
- Z7-P Dev Board & Kit with Zynq UltraScale+ MPSoC XCZU7EV.
- AXU5EVB-E Dev Board & Kit with Zynq UltraScale+ MPSoC ZU5EV.
- AXU4EVB-E Dev Board & Kit with Zynq UltraScale+ MPSoC ZU4EV.
- AXU3EGB Dev Board & Kit with Zynq UltraScale+ MPSoC ZU3EG.
- Z19 Dev Board & Kit with Zynq UltraScale+ MPSoC XCZU19EG.
- Z19-P Dev Board & Kit with Zynq UltraScale+ MPSoC XCZU19EG.
- AXU15EGB Dev Board & Kit with Zynq UltraScale+ MPSoC ZU15EG.
- AXU9EGB Dev Board & Kit with Zynq UltraScale+ MPSoC ZU9EG.
- FL6000 12-bit ADC AD9361 Communication RF FMC LPC Card.
- FL9781 14-bit 500 MSPS AD9781 Output Module LPC FMC Card.
- FL9031 4-channel Gigabit Ethernet LPC FMC Card.
- FL2971 3G-SDI 1080P Video Input/Output LPC FMC Card.
- FL9627 4-channel 12-bit 125M LVDS AD9627 Acquisition LPC FMC Card.
- FL2514 14-bit 250 MSPS AD Input Analog-to-Digital LPC FMC Card.
5) Downloads/Links
6) What is in the package
The package contains.
- 1 x System-on-module.
- 1 x Base board.
- 1 x Heatsink kit, preinstalled.
- 1 x USB downloader cable / set.
- 1 x 12 V power adapter.
- 1 x PCIe fence.
- 1 x Mini USB cable.
- 1 x Card reader.
- 1 x TF card.
