Description and Technical Data:
1) Overview/Key Features
The Z19-M is a heterogeneous computing development platform based on the Zynq UltraScale+ MPSoC XCZU19EG. It combines programmable logic, ARM processing, high-speed video interfaces, 100G optical networking, FMC expansion, DDR4 memory, and support for an optional NVIDIA Jetson Orin NX module. The platform is suitable for FPGA and GPU collaborative processing, edge AI, professional 8K video acquisition and processing, industrial control, medical imaging, robotics, intelligent transportation, and high-speed data-processing applications.
- Zynq UltraScale+ MPSoC XCZU19EG
- Quad-core ARM Cortex-A53 processor up to 1.3 GHz
- Dual-core ARM Cortex-R5F processor up to 533 MHz
- Mali-400 MP2 graphics processor
- 16 nm FinFET programmable-logic fabric
- 8 x HDMI 2.1 interfaces: 4 x input and 4 x output
- HDMI video support up to 8K at 60 Hz
- 8 x 12G-SDI interfaces supporting 4K at 60 Hz input or output
- 2 x 100G QSFP28 optical-fiber interfaces
- 1 x FMC HPC expansion connector
- Optional NVIDIA Jetson Orin NX module interface
- M.2 SSD and M.2 Wi-Fi/Bluetooth interfaces
- 1 x Gigabit Ethernet interface
- 4 x USB 3.0 Type-A and 1 x USB 3.0 Type-C interfaces
- DisplayPort and Micro SD interfaces
- 12 V single-supply input
- 280 x 163 mm board dimensions
