Description and Technical Data:
FL0214 is a 2-way 13 megapixel CMOS camera module with MIPI interface. The camera module adopts a CMOS photosensitive chip IMX214.
Product Description
FL0214 is a 2-way 13 megapixel CMOS camera module with MIPI interface. The camera module adopts a CMOS photosensitive chip IMX214.
FL0214 has a standard FMC LPC interface that can be connected to the ALINX FPGA carrier board for use.
Key Features
- ● Photosensitive Chip: SONY IMX214
● Resolution Ratio: 4208 *3120/4K/2K@30fps, 1080P@60fps
● Output Format: RAW10/8, COMP8/6
● Viewing Angle: 80.7°± 3° (Diag)
● Focusing distance: 10CM~infinity
● Camera output: CSI-2 serial data output (MIPI 4 Lane, compatible with D-PHY standard V1.1) - ● Focusing method: The motor automatically focuses
● Camera configuration interface: I2C
● MC20901 driver chip: level conversion (MIPI D-PHY ->LVDS)
● FMC LPC connector
● Working Temperature: -20°C-65°C
● Dimensions: 76.5 x 69 mm form factor
Module Features
Module Architecture
Click on the image to view a larger image.
Not all features are available simultaneously – please check the documentation for any applicable constraints.
All specifications are subject to change without notice. Please verify component specifications with vendor's datasheets.
ALINX provides product user manuals for each product.
What's Inside the Box
| FMC Cards | 1 |
|---|
Product Matrix
| Product Model | USD Price |
|---|---|
| FL0214 | 329 |
