Description and Technical Data:
1) Overview/Key Features
The Teltonika FMM800 is a compact, plug-and-play OBD-II vehicle tracker designed for fleet monitoring, vehicle rental, usage-based services, and other automotive telematics applications. It combines LTE Cat M1 connectivity, GNSS positioning, Bluetooth® connectivity, and an integrated accelerometer in a discreet OBD-II format.
Key features include:
- LTE Cat M1 cellular connectivity with fallback to GSM
- Internal high-gain GNSS and GSM antennas
- Plug-and-play OBD-II installation
- Integrated accelerometer
- Bluetooth® and Bluetooth Low Energy connectivity for compatible sensors, beacons, and accessories
- Real-time GPS tracking and configurable data transmission
- Green Driving and overspeeding detection
- Crash, towing, jamming, unplug, excessive-idling, and geofence detection
- Trip and odometer functions
- GNSS fuel-counter functionality
- Multiple power-saving modes, including Deep Sleep and Ultra Deep Sleep
- Configuration through Teltonika Configurator, SMS, GPRS commands, Bluetooth, and FOTA
- Internal backup battery
- IP41 protection rating
- Suitable for vehicle-rental, fleet-management, driver-behaviour, and asset-monitoring applications
The FMM800 is intended for professional installation and operation with a compatible tracking platform or telematics server.
Minimum orders apply. B2B customers please contact Mirifica Industrial for volume quotes. Mirifica Industrial ships world-wide.
2) Tech Specs
- Product type: OBD-II LTE Cat M1 vehicle tracker
- Model variant: FMM800-Q3IB0
- Cellular technology: GSM and LTE Cat M1
- LTE bands: B1, B2, B3, B4, B5, B8, B12, B13, B18, B19, B20, B25, B26, B27, B28, B66, and B85
- GNSS: Internal high-gain antenna
- Cellular antenna: Internal high-gain antenna
- Bluetooth: Bluetooth® and Bluetooth Low Energy
- SIM: Micro-SIM
- Vehicle interface: OBD-II connector
- USB: Micro-USB 2.0
- Power supply: 10–30 V DC
- Nominal voltage: 12 V DC
- Sensors: Integrated accelerometer
- Internal battery: Rechargeable backup battery
- Operating temperature: 0 °C to +45 °C
- Storage temperature: −20 °C to +45 °C for one month; −20 °C to +35 °C for six months
- Battery discharge temperature: −20 °C to +60 °C
- Ingress protection: IP41
- Configuration: Teltonika Configurator, Bluetooth, SMS, GPRS commands, FOTA, and FOTA Web
- Indicators: GNSS, cellular, and status LEDs
- Ignition detection: Accelerometer and external-power-voltage monitoring
- Supported events: Green Driving, overspeeding, jamming, excessive idling, unplugging, towing, crashes, geofencing, trips, and GNSS fuel counting.
3) Tech Support/Dokuments
Web available technical information usually covers installation, OBD-II connection, configuration, SIM-card insertion, LED indications, configuration, SMS commands, GPRS settings, data-acquisition settings, device status information, firmware updates, sleep modes, features, and certifications.
Fee-based technical support is available from Mirifica Industrial.
4) Related Product Suggestion
Manufacturer-documented add-on products and compatible accessories include:
- Teltonika Bluetooth® sensors
- Teltonika EYE beacons
- Bluetooth® Low Energy identification devices
- Bluetooth® door and status sensors
- OBD-II extension cable for installations where the vehicle’s OBD-II socket is difficult to access or needs to remain unobstructed.
5) Downloads/Links
6) What is in the package
The package contains.
- 1 × FMM800 tracker
- 1 × OBD-II power cable
- 1 × Micro-USB cable
- 1 × Quick Manual
