Description and Technical Data:
1) Overview/Key Features
The Queclink GL320CEU is a compact, battery-powered LTE asset tracker for real-time location monitoring of vehicles, equipment, parcels and other mobile assets. The European version is designed for LTE Cat M1/NB2 connectivity and GNSS positioning, with a self-contained battery, internal cellular and GNSS antennas, motion detection, configurable reporting and an emergency button. Please note the version with 1NCE eSIM currently in stock is ok for PoC and testing but the recharge is limited to 50MB each time and not optimal. The product is intended for professional users, to place orders the minimum are 100 units and you have to provide 100 eSIM to be sent to the factory for installation. Please contact Mirifica Industrial for the additional installation cost.
Typical applications for this excellent tracker include temporary vehicle tracking, package delivery, logistics, long-distance transport, personal security, endurance events and animal management.
Key features include:
- LTE Cat M1/NB2 connectivity for European deployments
- GNSS positioning using an integrated receiver
- Internal rechargeable lithium-polymer battery
- Up to approximately 300 hours of battery life when reporting every 10 minutes
- USB Type-C charging and configuration interface
- Internal cellular and GNSS antennas
- Motion detection through an internal 3-axis accelerometer
- SOS/emergency button with vibration feedback
- Scheduled, distance-based and mileage-based reporting
- Geofencing support
- Low-battery, power-on/off and motion alerts
- TCP, UDP and SMS transmission protocols
- IPX5 water-resistance rating
- Compact enclosure suitable for asset and vehicle tracking
Minimum orders apply. B2B customers please contact Mirifica Industrial for volume quotes. Mirifica Industrial ships world-wide.
2) Tech Specs
| Specification | Detail |
|---|---|
| Product model | GL320CEU |
| Product type | LTE asset tracker |
| Regional version | Europe |
| Cellular technology | LTE Cat M1/NB2 |
| Cellular fallback | 2G fallback may be available depending on the installed modem variant and network support |
| LTE Cat M1 bands | B1, B2, B3, B4, B5, B8, B12, B13, B18, B19, B20, B25, B26, B27, B28, B66 and B85 |
| LTE Cat NB2 bands | B1, B2, B3, B4, B5, B8, B12, B13, B18, B19, B20, B25, B28, B66, B71 and B85 |
| GNSS receiver | u-blox all-in-one GNSS receiver |
| GNSS sensitivity | Autonomous: -147 dBm; hot start: -156 dBm; reacquisition: -160 dBm; tracking: -162 dBm |
| Position accuracy | Less than 2.5 m CEP in autonomous operation |
| Dimensions | 77.9 × 39.9 × 26.7 mm |
| Weight | Approximately 93 g |
| Internal battery | 2,600 mAh lithium-polymer |
| Battery life | Approximately 480 hours without reporting; approximately 260 hours at 5-minute reporting; approximately 300 hours at 10-minute reporting |
| Water resistance | IPX5 |
| Charging voltage | 5 V DC |
| External battery voltage | Approximately 3.5–4.2 V DC |
| Operating temperature | -20 °C to +60 °C |
| Transmission protocols | TCP, UDP and SMS |
| Geofences | Up to 20 geographic fences |
| Inputs | One positive-trigger input for ignition detection and one negative-trigger input for general use |
| Buttons | Power button and function button with vibration feedback |
| Cellular antenna | Internal |
| GNSS antenna | Internal |
| Indicators | CEL, GNSS and PWR LEDs |
| USB interface | USB Type-C for external power, configuration and firmware update |
| Motion detection | Internal 3-axis accelerometer |
| Alerts | SOS/emergency, low battery, power on/off, motion and digital-input alerts |
The exact supported bands and modem functions should be confirmed against the GL320CEU hardware revision and the target operator network before deployment.
3) Tech Support/Dokuments
Web available technical information usually covers the GL320CEU’s European cellular connectivity, GNSS positioning, battery operation, reporting modes, geofencing, motion detection, alert functions, input configuration, USB Type-C interface, communications protocols, environmental characteristics, installation considerations and compatible accessories. Product documentation for this class of tracker generally includes hardware specifications, protocol information, configuration commands, installation guidance and fleet-platform integration details.
Fee-based technical support is available from Mirifica Industrial.
4) Related Product Suggestion
Manufacturer-listed related products and accessories include:
- GL300W
- GL300 magnetic case
- GL300 sheath
- Neoprene case
- USB-C data cable
- External battery kit
- External interface cable, Type-C
5) Downloads/Links
6) What is in the package
1 x product (contact Mirifica Industrial for additional configuration cables that may be needed with initial order for testing).
