Description and Technical Data:
Features
| Parameter | Rated value |
|---|---|
| Frequency Range | 617~960, 1410~1610, 1710~2690, 3300~7125 MHz |
| Polarization | Linear (vertical) |
| Gain | 4.5 dBi max |
| V.S.W.R | 3 max |
| Impedance | 50 Ω |
| Connector | SMA Male |
| Operating Temperature | -40 °C to +85 °C |
| IP rating | IP33 |
| RoHS Compliant | Yes |
| Weight | 24 g |
STANDARD ORDER CODES
| Order code | HS code | HTS code |
|---|---|---|
| PR1US540 | 851771 | 8517.71.00 |
