Description and Technical Data:
1) Overview/Key Features
The Teltonika PR313US3 is a 130 W desktop AC/DC power supply with a US Type A input plug and a 4-pin, 3 mm pitch output connector. It supplies 50 VDC at up to 2.6 A and is designed for compatible Teltonika equipment. Confirm voltage, connector and power requirements before use.
- 50 VDC output, up to 2.6 A
- 130 W output power
- US Type A input connector
- Short-circuit protection
- DoE Level VI efficiency standard
Minimum orders apply. B2B customers please contact Mirifica Industrial for volume quotes. Mirifica Industrial ships world-wide.
2) Tech Specs
| Specification | Detail |
|---|---|
| Input voltage | 100–240 VAC |
| Input voltage range | 90–264 VAC |
| Input frequency | 50/60 Hz |
| Input frequency range | 47–63 Hz |
| Input current | 2.5 A |
| Input connector | US (Type A) |
| Maximum input inrush current | 50 A |
| Output voltage | 50 VDC |
| Output voltage maximum deviation | 47.5–52.5 VDC |
| Output current | 2.6 A |
| Output connector | 4-pin, 3 mm pitch |
| Short-circuit protection | Yes |
| HIPOT (dielectric withstand test) | Primary to secondary: 4242 VDC |
| MTBF | 50,000 h |
| PSU efficiency standard | DoE Level VI |
| Weight | 600 g |
3) Tech Support/Dokuments
Web available technical information usually covers product features, ordering information and technical data, including input and output ratings, protection, efficiency and reliability specifications. Fee-based technical support is available from Mirifica Industrial.
4) Related Product Suggestion
No add-on products specifically identified for the PR313US3 were found on the manufacturer’s website.
5) Downloads/Links
6) What is in the package
- 1 x product
