Description and Technical Data:
1) Overview/Key Features
The Teltonika PR315USA is an 18 W power supply with a US (Type A) input connector. Its output connector is a 2-pin type with cord-end terminals. Order code: PR315USA.
Minimum orders apply. B2B customers please contact Mirifica Industrial for volume quotes. Mirifica Industrial ships world-wide.
2) Tech Specs
| Specification | Detail |
|---|---|
| Input voltage | 100–240 VAC |
| Input frequency | 50 / 60 Hz |
| Input current | 0.6 A |
| Input voltage absolute maximum | 90–264 VAC |
| Input frequency absolute maximum | 47–63 Hz |
| Input connector | US (Type A) |
| Inrush current | 60 A |
| Output voltage | 12 VDC |
| Output current | 1.5 A |
| Output voltage absolute maximum | 11.4–12.6 VDC |
| Output connector | 2-pin, with cord-end terminals |
| Short circuit protection | Yes |
| HIPOT (dielectric withstand test) | Primary to Secondary: 4242 VDC |
| MTBF | 50000 h |
| Weight | 106 g |
| Certification | Safety: CSA C22.2 No. 62368-1-14, 2nd Ed.; EMC: FCC Part 15, Subpart B: 2023; ANSI C63.4:2014 amended as per ANSI C63.4:2017 |
3) Tech Support/Dokuments
Web available technical information usually covers the product’s specifications and order code. Fee-based technical support is available from Mirifica Industrial.
4) Related Product Suggestion
No compatible products or add-on products are specified on the manufacturer’s product page.
5) Downloads/Links
- [DOWNLOAD DATASHEET](https://www.teltonika-networks.com/products/accessories/powering-options/us-2-pin-power-supply-18-w)
6) What is in the package
- 1 x product
