Description and Technical Data:
1) Overview/Key Features
The Teltonika PR324EUB is an EU single-port Gigabit passive PoE injector rated at 24 W. It supplies 24 VDC at up to 1 A and supports Gigabit Ethernet data transfer.
Minimum orders apply. B2B customers please contact Mirifica Industrial for volume quotes. Mirifica Industrial ships world-wide.
2) Tech Specs
| Specification | Detail |
|---|---|
| Product type | EU single-port Gigabit passive PoE injector |
| PoE technology | Passive |
| Input voltage | 100–240 VAC |
| Input frequency | 50 / 60 Hz |
| Input current | 0.8 A |
| Input connector | EU |
| Output voltage | 24 VDC |
| Output current | 1 A |
| Output power | 24 W |
| Data rate | 10 / 100 / 1000 Mbps |
| Ethernet connectors | 1 × RJ45 data input; 1 × RJ45 data and PoE output |
| MTBF | 3000 h |
| Weight | 295 g |
| Compliance | EN 61000; EN 62368; RoHS |
3) Tech Support/Dokuments
Web available technical information usually covers the injector’s power input and output, Ethernet data rate, connectors, and compliance specifications. Fee-based technical support is available from Mirifica Industrial.
4) Related Product Suggestion
No compatible add-on products are identified on the manufacturer’s product page.
5) Downloads/Links
6) What is in the package
1 x product
