Description and Technical Data:
1) Overview/Key Features
The REYAX RYLR896 is an 868/915 MHz LoRa® antenna transceiver module designed for long-range, low-power wireless communication. It uses the Semtech SX1276 LoRa® engine and provides high interference immunity, low receive current, high sensitivity, and a high-efficiency power amplifier. The module is suitable for industrial telemetry, environmental monitoring, metering, agriculture, security systems, smart-building applications, and other embedded IoT devices.
Key features include:
- 868/915 MHz LoRa® operation
- Ultra-long-range spread-spectrum communication
- Semtech SX1276 LoRa® engine
- RF output power from −4 to +15 dBm
- RF sensitivity down to −148 dBm
- High interference and blocking immunity
- Low receive and sleep current
- UART control through AT commands
- Built-in antenna
- Typical communication range of 4.5 km, with a stated maximum of 15 km depending on RF parameters and environmental conditions
- Operating voltage of 2.0–3.6 V
- NCC and FCC certification references
- Operating temperature from −40 °C to +85 °C
Minimum orders apply. NCNR non cancelable - non returnable product. B2B customers please contact Mirifica Industrial for volume quotes. Mirifica Industrial ships world-wide.
2) Tech Specs
| Specification | Details |
|---|---|
| Product type | LoRa® antenna transceiver module |
| Model | RYLR896 |
| Frequency range | 862–1020 MHz |
| Nominal frequency | 868/915 MHz |
| Supply voltage | 2.0–3.6 V |
| Typical supply voltage | 3.3 V |
| RF output power | −4 to +15 dBm |
| RF sensitivity | Down to −148 dBm |
| Maximum RF input level | 10 dBm |
| Filter insertion loss | 1–3 dB; typical 2 dB |
| Frequency accuracy | ±2 ppm |
| Transmit current | Typical 49.7 mA at +14 dBm |
| Receive current | Typical 16.5 mA |
| Sleep current | Typical 0.5 µA |
| UART baud rate | 300–115200 bps |
| UART format | 8-N-1 |
| Digital input high level | 0.7 × VDD to VDD |
| Digital input low level | 0–0.3 × VDD |
| Digital output high level | 0.9 × VDD to VDD |
| Digital output low level | Up to 0.1 V |
| EEPROM endurance | 300,000 erase/write cycles |
| Antenna | Built-in |
| Approximate weight | 3.07 g |
| Operating temperature | −40 °C to +85 °C |
The achievable range depends on antenna conditions, RF parameters, installation environment, interference, regulatory limits, and line of sight.
3) Tech Support/Dokuments
Web available technical information usually covers the RYLR896 electrical characteristics, RF performance, power consumption, UART interface, AT-command control, operating modes, antenna considerations, communication-range factors, installation requirements, and applicable certification information.
4) Related Product Suggestion
The Mirifica Industrial LoRa® product range includes related RYLR modules for other frequency bands and feature sets. The RYLR998 is a related 868/915 MHz module with a newer Nuvoton MCU and higher RF-output-power specification, while the RYLR498 is intended for 426/433/490 MHz applications.
5) Downloads/Links
RYLR896 manufacturer product page
Mirifica Industrial can supply any Reyax product. Minimum orders apply.
6) What is in the package
1 x product
