Description and Technical Data:
1) Overview/Key Features
The TE0836-01-TXE81-A is a compact RFSoC module based on the AMD Zynq™ UltraScale+™ RFSoC family. It combines high-performance programmable logic, embedded processing, high-speed RF data converters, DDR4 memory, clock generation, and essential system peripherals on a 90 mm × 65 mm module.
Key features include:
- AMD Zynq™ UltraScale+™ RFSoC ZU47DR-1E
- 8 × 12-bit RF ADCs
- 8 × 14-bit RF DACs
- 8 PL-GTY transceivers
- 4 PS-GTR transceivers
- 4 GByte DDR4 memory
- Dual QSPI flash memory, 128 MByte
- Programmable clock generator with SI5395A-A-GM PLL
- Gigabit Ethernet PHY
- USB 2.0 PHY
- TPM chip
- FPGA system oscillator
- 4 user LEDs
- CPLD-based system controller
- 2 × Samtec ADM6 board-to-board connectors
- 5 V to 12 V input supply voltage
- Compact 6.5 cm × 9 cm form factor
NCNR non cancelable - non returnable product. B2B customers please contact Mirifica Industrial for volume quotes. Mirifica Industrial ships world-wide.
2) Tech Specs
| Specification | Detail |
|---|---|
| Module type | RFSoC module |
| SoC family | Zynq™ UltraScale+™ RFSoC |
| Device | ZU47DR-1E |
| Possible RFSoC variants | ZU25DR, ZU27DR, ZU28DR, ZU42DR, ZU43DR, ZU47DR, ZU48DR |
| Speed grades | -1 and -2 options may be available depending on assembly configuration |
| Temperature options | Commercial and industrial temperature options may be available depending on assembly configuration |
| RF ADCs | 8 × 12-bit RF ADC |
| RF DACs | 8 × 14-bit RF DAC |
| PL transceivers | 8 × GTY |
| PS transceivers | 4 × GTR |
| MIO resources | 33 × single-ended |
| HP I/O resources | 48 × single-ended or 24 × differential |
| HD I/O resources | 20 × single-ended or 10 × differential |
| DDR4 memory | 4 GByte |
| QSPI memory | Dual QSPI, 128 MByte |
| I²C memory | 2-Kbit MAC EEPROM |
| Clock generator | Programmable PLL clock generator |
| Ethernet | Gigabit Ethernet PHY |
| USB | USB 2.0 PHY |
| Security | TPM chip |
| System controller | LCMXO2-640HC-4SG48I CPLD |
| User indicators | 4 × user LEDs |
| Board-to-board connectors | 2 × Samtec ADM6 connectors |
| Input supply voltage | 5 V to 12 V |
| Module dimensions | 90.0 mm × 65.0 mm |
| Form factor | 6.5 cm × 9 cm |
3) Tech Support/Documents
Web available technical information usually covers the module overview, key features, I/O resources, RF data-converter configuration, memory, power input, dimensions, connector arrangement, and available device assembly options. There are the following technical resources and support areas available through the product supplier: product information, technical documentation, configuration-related information, support contact, and project consultation.
Contact Mirifica Industrial for further detailed information for your project.
4) Related Product Suggestion
The product page does not identify specific add-on products for this exact module. Carrier-board selection and system accessories should be matched to the TE0836 interface, power requirements, mechanical dimensions, and intended RFSoC application.
5) Downloads/Links
6) What is in the package
The package contains.
- 1 x product
