Description and Technical Data:
1) Overview/Key Features
The AXVU9F is a high-performance FPGA development board and evaluation kit based on the Virtex UltraScale+ XCVU9P FPGA. It provides a flexible platform for compute acceleration, machine learning and AI, network acceleration, wired communications, 5G baseband, radar, test and measurement, emulation, and prototyping applications. The board combines high-speed FPGA interfaces, expandable FMC+ connectivity, 100G networking, DDR4 memory, QSPI Flash, and storage and video interfaces. alinx.com
- Virtex UltraScale+ XCVU9P FPGA
- 16 nm FinFET FPGA fabric
- Integrated 100G Ethernet MAC and 150G Interlaken cores
- 4 x FMC+ expansion connectors for compatible data acquisition, motor control, display, camera, and software-defined-radio modules
- 1 x 100G QSFP28 interface
- 1 x DDR4 SODIMM slot supporting up to 32 GB
- 2 x 128 MB QSPI Flash devices
- Gigabit Ethernet, USB-to-UART, JTAG, and SMA interfaces
- 12 V single-supply input
- 295 x 230 mm board dimensions
NCNR non cancelable - non returnable product. B2B customers please contact Mirifica Industrial for volume quotes. Mirifica Industrial ships world-wide.
2) Tech Specs
| Specification | Detail |
|---|---|
| FPGA device | XCVU9P-2FLGB2104 |
| FPGA family | Virtex UltraScale+ |
| FPGA process | 16 nm FinFET |
| Integrated FPGA cores | 100G Ethernet MAC and 150G Interlaken |
| DDR4 memory interface | 1 x SODIMM slot; supports up to 32 GB DDR4 |
| Included memory | 1 x 16 GB memory module |
| QSPI Flash | 2 x 128 MB |
| FMC+ connectors | 4 |
| FMC+1 | 120 I/O and 20 GTY lanes |
| FMC+2 | 120 I/O and 16 GTY lanes |
| FMC+3 | 72 I/O and 16 GTY lanes |
| FMC+4 | 72 I/O and 16 GTY lanes |
| QSFP28 | 1 x 100G interface, up to 100 Gbps |
| Ethernet | 1 x Gigabit Ethernet interface |
| UART | 1 x USB-to-UART interface |
| JTAG | 1 x JTAG interface |
| SMA | 2 x SMA interfaces; 1 x input and 1 x output |
| Power input | 12 V single supply |
| Board dimensions | 295 x 230 mm |
3) Tech Support/Documents
Web available technical information usually covers the board architecture, FPGA device, memory interfaces, FMC+ expansion, high-speed networking, storage, video connectivity, power requirements, supported applications, and included accessories. There are the following technical resources:
- AXVU9F V1.0 user manual
- Board feature and interface descriptions
- Technical specifications and product selection information
- Demonstrations and tutorials available for development support
Contact Mirifica Industrial for further detailed information for your project.
4) Related Product Suggestion
- NVIDIA Jetson Orin NX 16 GB package, supporting up to 100 TOPS
- NVIDIA Jetson Orin NX 8 GB package, supporting up to 70 TOPS
5) Downloads/Links
6) What is in the package
The package contains.
- 1 x AXVU9F development board
- 1 x preinstalled heatsink kit
- 1 x Mini USB cable
- 1 x USB downloader cable/set
- 1 x SMA wire
- 1 x SMA elbow
- 1 x 12 V power adapter
- 1 x 16 GB memory module
